江蘇民生重工有限公司
En
民生集團是無縫鋼氣瓶的領先制造商，例如氧氣瓶、CO2 氣瓶、N2 氣瓶、Ar 氣瓶、環氧乙烷氣瓶等。
我們提供各種尺寸的醫用氧氣瓶，并熱銷 10L/40L/47L/50L/68L/150bar/200bar 氧氣瓶。
我們?yōu)榭蛻舻目蛻籼峁└吒?jìng)爭力的價格
我們所有的醫用氧氣瓶在發貨前都經過嚴格的質量測試，以確保我們產品的高安全性。 我們是 SGS/TUV/ISO/CE/DOT/ASME 認證工廠。
我們可以根據客戶要求提供第三方測試報告，是值得信賴的氧氣瓶廠家。
產品參數:
| 外徑 | 水容積 | 高度 | 重量 | 工作壓力 | 設計壁厚 | 閥門型號 | 制造標準 | 材料 | 充裝介質 |
| Outside Diameter (mm) |
Water Capacity (L) |
High (without valve）(mm) |
Weight (without Valuve&Cap) (kg) |
Working Pressure (Mpa) |
Design wall thickness (mm) |
Model of valve |
Manufacturing standard |
Material | Filing Medium |
| 108 | 1.5/2.0/2.5/3.0/3.5 4.0/4.6/5.0 |
255/315/375/435 498/555/625/675 |
2.7/3.1/3.5/3.9/4.6/ 4.9/5.4/5.7 |
15 | 2.6 | QF,CGA or customer reauirements |
IS09809 /GB5099/ EN TPED/DOT /KGS |
30CrMo | O2 Argon Helium CO2 H2, etc. SF6/CF4/ N2O/Xe/Ne/ Kr/C2H4/CO H2S/HBr SiH4/C2H6, etc. |
| 140 | 3.4/4/5/6/6.8/7 17.4/8/9/10/10.2 /13.4 |
340/390/460/530/ 575/600/640/690/ 770/840/850/1090 |
6.5/7.1/8.3/9.4/10/ 10.5/11/12/13/14/ 14.2/17.5 |
15 | 3.6 | 37Mn | |||
| 165 | 7/8/9.5/10/10.3/12/ 13/13.5/15 |
490/540/615/630/65 0/750/805/840/915 |
12/13/14.5/14.5/15/ 17/18.3/19/21 |
15 | 4.3 | 37Mn | |||
| 178 | 718/10/11/12 /15/20/21/24/27 |
420/465/555/600/ 650/785/1015/1060/ 1195/1320 |
12/13/15/16.2 17/20/25/26/29.5/32.5 |
20 | 4.6 | 30CrMo | |||
| 219 | 19/20/25/27/ 28/36/38/40/42/47 |
685/725/875/935 955/1195/1255/ 1315/1375/1525 |
27/28/33/35/ 36/44/46/48/50/55 |
15/12.5 | 5.7 | 37Mn | |||
| 229 | 40/47/50 | 1240/1430/1510 | 55/62/65 | 15 | 5.2 | 34CrMo4 | |||
| 229 | 38/40/42/44/46 | 1180/1230/1285/ 1340/1390 |
47/48/50/52/55 | 15 | 5.2 | 30CrMo | |||
| 229 | 30/35/40/42 | 970/1100/1240/1300 | 45.5/51/56/58 | 2015/12532H | 6.2 | 30CrMo | |||
| 229 | 30/35/40/45/47/50/ 52 |
955/1095/1235/1370 1425/1505/1560 |
42/48/54/59/ 61/64/66 |
20 | 6.2 | 30CrMo | |||
| 232 | 36/38/40/43.3/44 /45/46.7/47/50 |
1085/1130/1190 1270/1295/1320/ 1365/1370/1450 |
43/44/46/49/49.5 /50/52/52/55 |
15 | 5.4 | 37Mn | |||
| 235 | 38/40/42/47/50 | 1130/1180/1230 1365/1435 |
50/53/56/59/62 | 15 | 5.2 | 30CrMo | |||
| 267 | 34/40/50/58/60/67 167.5/68/70/80/82 |
815/925/1130/1290 1330/1465/1480/1480 /1530/1725/1765 |
44149/55/611/62/69 /70/70/72/80/82 |
15137H2582 | 6 | 37Mn | |||
| 267 | 34/50/58/60/67/68/ 70/80/82 |
815/1140/1300/ 1340/1485/1500/ 1540/1740/1780 |
43/59/66/68/75/76/78/ 87/88 |
15137H2582 | 6.3 | 37Mn | |||
| 267 | 60/68/80 | 1340/1500/1750 | 70/78/89 | 15 | 6.3 | 30CrMo | |||
| 267 | 50/60/67.5/68/70 /75/80/82.5 |
1140/1340/1480 1480/1540/1640 1740/1790 |
61/70/78/78/80/85/ 90/93 |
172 | 6.6 | 30CrMo | |||
| 267 | 50/60/70/75/80 | 1230/1430/1630/ 1730/1830 |
66/76/86/91/96 | 20/15 | 7.5 | 30CrMo | |||
| 279 | 40/70/75/80/82 | 910/1450/1540/ 1630/1665 |
52/82/87/92/94 | 15 | 6.3 | 30CrMo | |||
| 279 | 50/70/80/82/82.5/87 | 1075/1445/1630/ 1655/1655/1745 |
65/80/92/94/94/98.5 | 17.2 | 6.6 | 35CrMo | |||
| 279 | 50/60/68/70/80/82/ 90 |
1065/1250/1400 1435/1620/1645/1805 |
61/70/77/79/88 30/1005 |
15 | 6.6 | 37Mn | |||
| 279 | 70/75 | 1450/1540 | 82/87 | 16.5 | 6.7 | 30CrMo | |||
| 279 | 70/75/80/82/90 | 1430/1520/1615/ 1650/1800 |
85/90/95/97/105 | 17.2 | 7 | 30CrMo | |||
| 279 | 50/60/70/75/80/82 | 1090/1280/1460/1550 /1640/1675 |
78/89/99/103/ 109/112 |
17.2/15 | 7 | 30CrMo |
